Bushey Hall Winchmaster S3300 24V Winch with Mount - Used Ex-MOD

Delivery on pallet - don't choose Next Day Shipping

The Bushey Hall Winchmaster S3300 is a heavy-duty 24V electric recovery winch, originally commissioned for the British Ministry of Defence (MOD). This unit is specifically designed for technical recovery and utility tasks, offering a rated line pull of 3,300kg (approx. 32.4kN). This particular listing includes the genuine military vehicle mount, allowing for secure, low-profile installation on service-issue trucks, utility vehicles, or custom recovery trailers. Built around a robust planetary gear system, it is engineered for consistent torque and mechanical longevity in high-stress field environments.

Technical Performance & Build

• Ex-MOD Specification: Genuine service-issue hardware manufactured to the exacting standards required for British military recovery operations.

• Heavy-Duty Mounting: Includes the original steel mounting plate, designed to distribute load forces evenly across the vehicle chassis or mounting surface.

• 24V Series-Wound Motor: Provides high-torque output for consistent pulling power, specifically designed for 24V vehicle electrical systems.

• Planetary Gearing: Features a compact, high-efficiency gearbox that ensures smooth power delivery and durability under maximum rated loads.

• Rope Configuration: Fitted with approximately 23 metres of 9mm high-tensile rope, providing a safer and more manageable alternative to traditional steel wire.

• Automatic Load Holding: Equipped with an internal drum brake system that automatically secures the load when the motor is disengaged.

• Environmental Protection: The low-profile housing is designed to shield internal components from the ingress of mud, grit, and water during field use.

Technical Specifications

• Voltage: 24V DC

• Rated Line Pull: 3,300kg (Single Line)

• Rope Diameter: 9mm

• Approx. Rope Length: 23 Metres

• Mounting: Includes Military Vehicle Mounting Plate

• Compliance: Originally built to EN14492-1 standards for power-driven winches.

Realistic Use Cases

Once the unit has been professionally inspected and certified for safety, it is highly effective for:

• Military Vehicle Restorations: An essential component for authentic ex-MOD truck or Land Rover 101/Defender 130 recovery builds.

• Specialist Transporters: Ideal for mounting on 4x4 recovery vehicles, beaver-tail trailers, or plant machinery transporters.

• Agriculture & Forestry: Providing a high-capacity, fixed-point pulling solution for clearing timber or moving heavy farm implements.

Condition & Safety Compliance

This item is genuine military surplus and is sold in used condition.

Important Safety Notice: This winch is sold as uncertified and without guarantee of functional performance. As ex-MOD equipment, it will show visible signs of service use, including paint scuffs, surface corrosion on the plate, or cosmetic wear. Under UK health and safety regulations, this unit must be inspected, serviced, and certified for safe operation by a qualified winch technician before installation or use in any lifting or recovery capacity.
